The PW-250 Series Curtain Wall System combines high-quality construction with optimum performance, tailored to meet the requirements of demanding architectural wall systems. Besides enhancing the architectural design and aesthetic appeal, GAMCO also provides structural design and analysis along with a full line of drafting production services. Our systems allow for factory assembly, unitizing and outside glazing without compromising integrity.
*Options: ¼” to 1” reducers
Finishing:
Clear Anodized
Dark Bronze Anodized
Custom Finishes Available
| GAMCO Product | Gamco Model/Description | Wall Thickness | Frame Depth | Profile | Wholesale Stock Lenghts Available | Glazing Thickness | Minimum Size | Maximum Size without structural Reinforcement | Air-Std | Water-psf | Deflect-psf | Struct-psf | Colors | Stainless Steel Cladding Available |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | PW-250 Pressure Wall System | 0.100 | 2-3/8" | 2-1/2" | YES | 1/4" or 1" | 12" x 12 " | 12' x 12' | * | * | * | * | Clear Anodized Dark Bronzed Anodized | YES |
| 0.100 | 3-7/8" | 2-1/2" | YES | 1/4" or 1" | 12" x 12 " | 15' x 15' | * | * | * | * | YES | |||
| 0.125 | 5-1/2" | 2-1/2" | YES | 1/4" or 1" | 12" x 12 " | 15' x 30' | <0.01 | 15 | 60 | 90 | YES |
| PERFORMANCE | ||
|---|---|---|
| Type | Description | Curtain Wall |
| Size | (Width X Height) | 15′-0″ X 30′-0″ |
| ASTM E 283-04 | Static Pressure Air Infiltration 6.24 Psf | 0.01 CFM/SQFT |
| ASTM E 331-00 | Static Pressure Air Water Resistance | 15 PSF |
| ASTM E 330-02 | Uniform Structural Load ± Pressure | 60 PSF |
| Uniform Structural Over Load ± Pressure | 90 PSF | |
| AAMA 501-1-05 | Dynamic Pressure Water Resistance | 15 PSF |
| Interstory Difference Movement (Horizontal Cycling) Left & Right (No Damage) 1.2″ |
||
Download:
Brochure-Curtain Wall
Catalog-Gamco Product Lines
Catalog-Product Architectural Details
Test Reports:
Curtain Wall Acoustical Test Report
Curtain Wall Thermal Test Report
Curtain Wall CW250 Sound Test Report
Curtain Wall CW250 Structural Test Report
Curtain Wall CW250 Thermal Test Report
| GAMCO Product/Type | Drawing-PDF File | Drawing-CAD File | |
|---|---|---|---|
 | 2-1/2″ x 2-3/8″ Member with Windows | 2-1/2″ x 2-3/8″ Member with Windows | 2-1/2″ x 2-3/8″ Member with Windows |
 | 2-1/2″ x 3-7/8″ Member with Narrow Stile Door | 2-1/2″ x 3-7/8″ Member with Narrow Stile Door | 2-1/2″ x 3-7/8″ Member with Narrow Stile Door |
 | 2-1/2″ x 3-7/8″ Member with Windows | 2-1/2″ x 3-7/8″ Member with Windows | 2-1/2″ x 3-7/8″ Member with Windows |
 | 2-1/2″ x 5-1/2″ Member with Narrow Stile | 2-1/2″ x 5-1/2″ Member with Narrow Stile | 2-1/2″ x 5-1/2″ Member with Narrow Stile |
